Technical Specifications

Camera Hardware Profile

• 1/2.7" 1-megapixel progressive CMOS sensor
• 16 ft night vision with infrared LEDs
• Minimum illumination: 0 lux with IR LEDs on
• Built-in microphone
• 8x digital zoom
• Focal length: 1.72 mm
• Aperture: F2.0
• Angle of view:
  • (H) 180°
  • (V) 120°
  • (D) 180°

External Device Interfaces

• Power LED

• Reset button
• WPS button
• microUSB power connector
• microSD/SDXC card slot

Image Features

• Adjustable image size, quality, frame rate and bit rate
• Adjustable brightness, saturation, contrast, sharpness and hue
• Configurable motion and sound detection
• Time stamp and text overlays

Video Compression

• Simultaneous H.264/MJPEG format video compression
• JPEG for still images

Video Resolution

• 1280 x 720 at up to 30 fps
• 800 x 600 at up to 30 fps
• 720 x 480 at up to 30 fps
• 640 x 480 up to 30 fps
• 320 x 240 up to 30 fps

Audio Support

• AAC
• G.711

Mobile Support

• mydlink Lite app available for iOS, Android devices and Windows Phones
• mydlink + app available for iOS and Android devices

Network

Network Protocols

• IPv4, ARP, TCP, UDP, ICMP
• DHCP Client
• NTP Client (D-Link)
• DNS Client
• DDNS Client (D-Link)
• SMTP Client
• FTP Client
• HTTP Server
• PPPoE
• UPnP, UPnP port forwarding
• RTP, RTSP, RTCP
• HTTPs for configuration
• Bonjour

Security

• Administrator and user group protection
• Password authentication
• HTTP and RTSP digest encryption

Physical

Dimensions (H x W x D)

• 3.78 x 3.78 x 5.43 inches

Weight

• 0.31 lbs (camera only)

Power Input

• 5 V DC / 1.2 A, 50/60 Hz through power adapter

Temperature

• Operating: 0 to 40 °C (32 to 104 °F)
• Storage: -20 to 70 °C (-4 to 158 °F)

Humidity

• Operating: 20% to 80% non-condensing
• Storage: 5% to 95% non-condensing

Certifications

• CE
• CE LVD
• FCC Class B
• ICES
